Data for vibration of single deep groove ball bearing
The vibration and noise of bearings are classified as four classes measured by BVT-1 and classified as V1, V2 ,V3 and V4.
Data for vibration of single deep groove ball bearing
Tolerance in μm/s.
|
d mm |
V | V1 | V2 | V3 | V4 | ||||||||||
|
Low Band |
Medium Band |
High Band |
Low Band |
Medium Band |
High Band |
Low Band |
Medium Band |
High Band |
Low Band |
Medium Band |
High Band |
Low Band |
Medium Band |
High Band |
|
|
3,4 5,6 7,8,9 10,12 15 17 20 22,25 28 30,32 35 40 45 50 55 60 |
80 110 130 160 210 210 260 260 260 300 300 360 360 420 420 480 |
44 72 96 120 150 150 190 190 190 240 240 300 300 320 360 360 |
44 60 80 100 120 120 150 150 150 190 190 260 260 320 360 440 |
60 74 92 120 150 150 180 180 180 200 200 240 240 280 280 320 |
35 48 66 80 100 100 125 125 125 150 150 180 180 200 220 220 |
32 40 54 70 85 85 100 100 100 130 130 160 160 200 200 240 |
48 58 72 90 110 110 130 130 130 150 150 180 180 210 210 240 |
26 36 48 60 78 78 100 100 100 120 120 150 150 160 180 180 |
22 30 40 50 60 60 75 75 75 100 100 130 130 160 180 200 |
31 35 44 55 65 65 80 80 80 90 90 110 110 125 120 145 |
16 21 28 35 46 46 60 60 60 75 75 90 90 100 110 110 |
15 18 24 30 35 35 45 45 45 60 60 80 80 100 110 130 |
28 32 38 45 52 52 60 60 60 70 70 82 82 95 95 100 |
10 11 12 14 18 25 25 30 35 35 42 50 60 70 70 80 |
10 11 12 15 18 25 25 32 40 40 45 50 60 70 70 80 |
Tolerance in μm/s.
|
d mm |
V | V1 | V2 | V3 | V4 | ||||||||||
|
Low Band |
Medium Band |
High Band |
Low Band |
Medium Band |
High Band |
Low Band |
Medium Band |
High Band |
Low Band |
Medium Band |
High Band |
Low Band |
Medium Band |
High Band |
|
|
65 70 75 80 85 90 95 100 105 110 115 |
300 360 360 420 420 480 480 560 560 640 640 |
260 310 310 360 360 420 420 490 490 570 570 |
420 460 460 540 540 600 600 670 670 750 750 |
180 200 200 240 240 290 290 340 340 400 400 |
160 180 180 210 210 250 250 300 300 350 350 |
240 280 280 320 320 370 370 420 420 480 480 |
130 150 150 180 180 210 210 250 250 290 290 |
100 120 120 120 120 180 180 215 215 260 260 |
150 200 200 240 240 270 270 310 310 350 350 |
105 110 110 130 130 145 145 170 170 190 190 |
80 90 90 110 110 125 125 145 145 175 175 |
105 135 135 160 160 180 180 200 200 225 225 |
50 58 58 65 65 75 75 88 88 100 100 |
50 58 58 65 65 75 75 88 88 100 100 |
75 88 88 100 100 115 115 135 135 160 160 |
dB noise testing
The noise of bearings by dB is classified as four classes as Z1, Z2, Z3 and Z4. It is measured by the instrument of S0910-1.
Maximum vibration acceleration of single bearing
Tolerance in dB
|
d mm |
Diameter Series (0) | Diameter Series (2) | Diameter Series (3) | ||||||||||||
| Z | Z1 | Z2 | Z3 | Z4 | Z | Z1 | Z2 | Z3 | Z4 | Z | Z1 | Z2 | Z3 | Z4 | |
|
3 4 5 6 7 8 9 10 12 15 17 20 22 25 28 30 32 35 40 45 50 55 60 |
35 35 37 37 39 39 41 43 44 45 46 47 47 48 49 49 50 51 53 55 57 59 61 |
34 34 36 36 38 38 40 42 43 44 44 45 45 46 47 47 48 49 51 53 54 56 58 |
32 32 34 34 35 35 36 38 39 40 40 41 41 42 43 43 44 45 46 48 50 52 54 |
28 28 30 30 31 31 32 33 34 35 35 36 36 38 39 39 40 41 42 45 47 49 51 |
24 24 26 26 27 27 28 28 29 30 30 31 31 34 35 35 36 37 38 42 44 46 48 |
36 36 38 38 40 40 42 44 45 46 47 48 48 49 50 50 51 52 54 56 58 60 62 |
35 35 37 37 38 38 40 42 43 44 45 46 46 47 48 48 49 50 52 54 55 57 59 |
32 32 34 34 36 36 37 39 39 41 41 42 42 43 44 44 45 46 47 49 51 53 54 |
30 30 32 32 34 34 35 35 35 36 36 38 38 40 41 41 42 43 44 46 48 50 51 |
26 26 28 28 29 29 30 30 30 31 31 33 33 36 37 37 38 39 40 43 45 47 48 |
37 37 39 39 41 41 43 46 47 48 49 50 50 51 52 52 53 54 56 58 60 62 64 |
36 36 37 37 39 39 41 44 45 46 47 48 48 49 50 50 51 52 54 56 57 59 61 |
33 33 35 35 37 37 39 40 40 42 42 43 43 44 45 45 46 47 49 51 53 54 56 |
31 31 33 33 35 35 37 37 37 38 38 39 39 41 42 42 43 44 45 47 49 51 53 |
27 27 29 29 30 30 32 32 32 33 33 34 34 37 38 38 39 40 41 44 46 48 50 |
Maximum vibration acceleration of single bearing
Tolerance in μm/s.
|
d mm |
Diameter Series (0) | Diameter Series (2) | Diameter Series (3) | |||||||||
| Z | Z1 | Z2 | Z3 | Z | Z1 | Z2 | Z3 | Z | Z1 | Z2 | Z3 | |
|
65 70 75 80 85 90 95 100 105 110 120 |
49 50 51 52 53 54 56 58 60 62 64 |
48 49 50 51 52 53 55 57 59 61 63 |
46 47 48 49 50 52 54 56 58 60 62 |
41 42 43 44 45 47 49 51 53 55 57 |
50 51 52 53 54 56 58 60 62 64 66 |
49 50 51 52 53 55 57 59 61 63 65 |
47 48 49 50 51 53 55 57 59 61 63 |
42 43 44 45 46 48 50 52 54 56 58 |
51 52 53 54 56 58 60 62 64 66 68 |
50 51 52 53 55 57 59 51 63 65 67 |
48 49 50 51 52 54 56 58 60 62 64 |
43 44 45 46 47 49 51 53 55 57 59 |
